PV-JM801D-1.2

Series:

While making continuous efforts to seek talents, Jiaming aims to cultivate and bring up a talent team that pioneers the market, creates organizational advantages, leads value orientation, and has a sense of mission and responsibility to support the realization of strategic goals.

Main features:

● The shell has strong anti-aging and UV resistance;

● Meets the requirements for use in harsh outdoor environments;

● Quick welding strip installation, all connection methods use double reinforced connection methods;

● Equipping different specifications of diodes will change the maximum operating current of the junction box.

● Latest certification standards: IEC62790:2014 UL3730

Product Inquiry

Technical Parameters:

Model: PV-JM801D-1.2(TUV)		Model: PV-JM801D-1.2(UL)
Electrical Characteristics		Electrical Characteristics
Rated Voltage: 1000V DC		Rated Voltage: 600V DC
Contact Resistance: ≤5mΩ		Contact Resistance: ≤5mΩ
Safety Class: Class Ⅱ		Safety Class: Class Ⅱ
Mechanical Characteristics		Mechanical Characteristics
Temperature Range: ﹣40℃ ～ +85℃		Temperature Range: ﹣40℃ ～ +90℃
Cable Range: 4mm2 6mm2		Cable Range: 12AWG 10AWG
Protection Class: IP 67, Matching		Protection Class: IP 67, Matching
Material Characteristics		Material Characteristics
Insulation Material: MPPO/PA, Black		Insulation Material: MPPO/PA, Black
Contact Material: Copper, Tin-plated		Contact Material: Copper, Tin-plated
Flammability Rating: UL94-V0		Flammability Rating: 5VA
Product Family:
Model	Current at Junction Temperature	Certificates
PV-JM801D-1.2	15A	TUV	UL
